Bluetooth DAC FiiO BTR17 ES9069Qx2

FEATURES

◉ Flagship Qualcomm Bluetooth platform QCC5181, Bluetooth 5.4

◉ Supports LDAC, aptX Lossless Physical control knob

◉ Desktop mode 650mW+650mW powerful output Dual flagship DACS ES9069Q*2

◉ 10-band high-precision PEQ

◉ XMOS 16-core XU316 Four-way full balanced THX AAA 78+ amps

◉ Multi-stage HiFi audio architecture

SPECIFICATIONS

•USB chip: XMOS XU316

•USB DAC: 768kHz-32bit, DSD512 native, MQA full decoding

•USB DAC driver-free mode: Supported

•Bluetooth chip: QCC5181

•Bluetooth version: 5.4

•Bluetooth formats supported: AAC/SBC/aptX/aptX Adaptive/aptX Lossless/aptX HD/LDAC

•DAC: ES90690*2

•Display: 1.3-inch 240x240 color IPS

•Battery life: About 8 hours (LDAC)

•Charging time: <2H

•Headphone outputs: Single-ended 3.5mm + balanced 4.4mm

•Output power 1: L+R>280mW+280mW (320/THD+N <1%/single-ended/desktop mode)

•Output power 2: L+R231mW+31mW (3000/THD+N <1%/single-ended/desktop mode)

•Output power 3: L+R≥650mW+650mW (320/THD+N <1%/balanced/desktop mode)

•Output power 4: L+R≥125mW+125mW (3000/THD+N <1%/balanced/desktop mode)

•Output power 5: L+R≥300mW+300mW(320, THD+N <1%/balanced/non desktop mode)

•Output power 6: L+R≥140mW+140mW (320, THD+N <1%/single-ended/non desktop mode)

•Signal-to-noise ratio: ≥126dB (UAC decoding, desktop mode, A-weighted)

•THD+N: <0.00035% (UAC decoding, desktop mode, balanced output)

•Dimensions: About 16.3×41.2×86.6mm

•Weight: About 73.4g

•Color: Black/Blue
